Basic Info.

Model NO.	ECN000-09P-EM-23S
Housing Materials	Aluminium Alloy
Dielectric Strength	≥[email protected](power) ≥[email protected](signal)
Electrical Noise	≤70mΩ
isolation Resistance	500MΩ@300VDC 100MΩ@300VDC
Rating Voltage	24VDC
Circuit & Current	4*10A,3*5A,3*2A,23*signal, 1*1A,2*1A,1*100M Ethern
Transport Package	Carton Box
Specification	Precious metal / Alloy / Engineer plastic
Trademark	CENO
Origin	Shen Zhen, China
Production Capacity	50000pieces/Year

Product Description

CENO has developed signal slip ring with 100M/1000M Ethernet signal character base on market requirement.The Ethernet slip ring comply with EMC compatibility and meet the requirement of Signal impedance matching, to make sure transmission low loss, no error code,long distance transmission. Features Easy to install,as well asintegrate hydraulic,pneumatic,fiberoptical,RF rotary joint Low friction, long life,low torque,smooth rotation Transmit data and analog signal,compatible with data bus protocol
Applications Radar antenna Construction engineering Package equipment Lithium battery equipment
Optional Circuit number Current rating ousing material IP protection grade

Product Parameters

ECN000-09P-EM-23S	Specification
Current	4*10A,3*5A,3*2A(1*2A*PE),23*signal, 1*1A,2*1A,1*100M Ethernet
Voltage	24VDC
Electrical noise	≤70mΩ(50rpm)
Dielectric strength	≥[email protected](power) ≥[email protected](signal)
Insulation resistance	500MΩ@300VDC(power) 100MΩ@300VDC(signal)
Operating speed	0-300 rpm
Contact material	precious metals
Operating temperature	-40~+70ºC
Housing material	aluminum alloy
IP protection grade	IP54

Outline drawing
