Fiber optic rotary joint with SM/MM & high speed  (0~20000rpm optional )

Overview

Basic Info.

Model NO.	FCN01G-10H
Weight	15g
Return loss	≥50dB
Insertion loss	<1.5dB
Wavelength	850nm -1550nm (SM/MM)
Fiber channel	1
Transport Package	Carton Box
Specification	Precious metal / Alloy / Engineer plastic
Trademark	CENO
Origin	Shen Zhen, China
Production Capacity	50000pieces/year

Product Description

The series of fiber optic slip rings consists of one fiber channel and can be also single or multimode.Made with a beam expanding process, no contact friction, so it can adapt to very high speeds,such as20000rpm and long life. its small size make it suitable for applications where space is rather small. This product is one of our standard products ,long-term material preparation, support for fast delivery.
Features Apply to single mode or multimode photoelectric rotary connection Transmit signal via fiber optic,nodisclose,no EMI Convenient to integrate powerslip ring
Applications Radar system Medical equipment Military equipment
Optional Fiber channel number Connector type Fiber type Fiber length

Product Parameters

FCN01G-10H	Specification
Fiber type	SM/MM
Fiber channel	1
Wavelength range	850~1650nm
Return loss	<1.5dB
Rotation speed,max	20000rpm
Operation temperature	-20ºC~+60ºC
Weight	15g
IP grade	IP54
Power handing peak	≤23dBm

Outline drawing
